A-Scan ultrasound probe – 4Sight platform compatible

Description

High quality visuals

Record and save unlimited images and videos with the B-scan probe and the Keeler 4Sight™ software, to assist with diagnosing, record keeping and even teaching future generations of eye care professionals.

Featuring optimised lens constants for improved visuals, the A-scan probe allows you to see visuals that would otherwise be obscured by cataracts or vitreous haemorrhages, providing superior surgical outcomes for your patients.

Easy to use interface

The smooth interface makes the A-scan probe easy to use, and allows you to create default settings that you can go back to again and again without interruptions. The system also automatically creates electronic medical records for your patients, giving you peace of mind for future examinations.

Wavelength spike patterns

Working on 10 MHz broadband, the A-Scan probe can be used to measure ocular axial length in both contact or immersion modes. Each measurement with the A-scan captures up to 5 wavelength spike patterns, using independent velocities for each portion of the eye, as well as the average and standard deviation of each anatomical measurement to give you the most accurate results.

IOL formulas

Includes 6 IOL formulas: Hoffer Q, SRK/T, Holladay I, Haigis, SRK II, Binkhorst II.

Post refractive formulas

The A-scan also has post refractive measurement capabilities, using 4 formulae: Contact Lens, Entered, Clinical History and Shammas Clinical.

Great value

At Keeler, we believe that value is more than the price alone. We look at every detail and quality components, results and high build quality shouldn’t cost the earth.

Support when you need it

True partnerships don’t stop, our industry-leading warranty and service programs, as well as our live help facility offer dependable support for the life of the product.

Features – A-Scan probe:

• Immersion and contact modes
• Customizable lens, ACD and VCD materials for new emerging implant/chamber materials
• Optimized lens constants for superior surgical outcomes
• Easy to set up defaults, smooth customer interface and automatic EMR exports to decrease examination time, increase patient throughput, and increase profit
• Automatic alignment detection and sclera recognition help eliminate marginally aligned scans
• Seamless work flow integration with IOLMaster 500 from ZEISS
• Fully upgradeable software
• Unlimited data storage based on PC/network storage
• EMR capability with automatic transfer of data
  DICOM ready
• Unlimited IOL Lens groups
• Piggyback calculation ability for ICL implant patients
• Rx surgery calculations for an aging Lasik population
• PC based platform
• PDF reporting

Specification:

• Capture Modes: Automatic or Manual
• Clinical Accuracy: 0.1mm
• Custom Eye Type Settings: Unlimited with independent ACD, Lens, VCD velocities.
• Data Export: EMR/EHR compatible, Network ready
• Default Eye Type Settings: Phakic, Dense Cataract, Silicone Filled, Pseudo PMMA, Pseudo Silicone, Pseudo Acrylic, Aphakic
• Dimensions: 5.4″W x 3.7″L x 2.5″H
• Electronic Resolution: 0.016mm
• Frequency: 10MHz
• Gain: 30-100dB
• IOL Data Storage: Unlimited
• Measurement Range: 0.01-63.6mm
• Measurements: ACD, Lens thickness, VCD, Axial Length
• Methods: Immersion or contact
• Patient Data Storage: Unlimited
• Post Refractive Formula Methods: Clinical History, Contact Lens, Shammas Clinical
• Printer: Any supported by PC
• Weight: 15.1 oz
